Ergotron 45-479-216 HX Wall Dual Monitor Arm (White)

$745.95
SKU 45-479-216

Ergotron 45-479-216 HX Dual Monitor Arm adds ergonomic adjustability to your heavy duty monitors or TVs. Install a dual monitor set up on sturdy vertical surfaces or a wall with this HX arm and take advantage of this arm's curved hinged bow which grants viewing comfort. Mount monitors and TVs up to 32" in size and weighing between 5-17.5 lbs on this arm. Use the handle underneath the monitors to lift them up or down 11.5" and extend 24.5" to position them according to your preference.

Specifications

  • UPC: 698833054538
  • Part Number: 45-479-216 (white), 45-479-026 (polished aluminum)
  • Description: HX Wall Dual Monitor Arm
  • Includes arm, extension, hinge bow, (2) monitor pivots, handle, wall mount and monitor mounting hardware
  • Arm folds back over the base into a compact retracted position; perfect for tucking under systems furniture storage shelves or cabinets in space constrained areas
  • Portrait/landscape rotation with lockout
  • Streamline cable management that routes cables under arm and within extension
  • ‡ Mounting Standards: VESA FDMI MIS–D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm). The optional VESA Bracket Adaptor Kit (97-759) allows the attachment of displays with VESA hole patterns of 200 x 100, 200 x 200, 400 x 200 mm, 400 x 300 mm or 400 x 400 mm
  • Mounting Options: Attaches directly to sturdy vertical surfaces. Where applicable, apply to wood stud. Also attaches to wall track using bracket 97-091 (order separately)
  • * Weight Capacity: Individual LCD weight = 5–17.5 lbs (2.3–7.9 kg) per monitor. Total LCD weight = 10–35 lbs (4.6–15.8 kg)
  • Monitor depth greater than 2.5" (6.4 cm) may diminish capacity
  • Hinge bow turns 40° inward and 90° outward
  • ** Monitor can be rotated 360° at connection point of arm and extension; rotation is restricted to 180° at connection point of extension and base
  • † Tilt Range: 70° backward, 5° forward
  • Pivots feature quick install and release and feature effortless portrait to landscape 6° pan and tilt
  • Up to 24.5" (60 cm) extended reach and 11.5" (29.2 cm) vertical height adjustment
  • Product Weight: 18.8 lb (8.5 kg)
  • Shipping Dimensions: 16" x 18.8" x 7.5" (48 x 41 x 19 cm)
  • Shipping Weight: 26.9 lbs (12.2 kg)
  • Warranty: Ten (10) years
