Ergotron HX Triple Monitor Bow Kit

Sold out
$426.00
SKU 98-009-216

The HX Triple Monitor Bow Kit upgrades an HX arm to hold three monitors and includes a handle for easy positioning. It’s the perfect accessory to expand your view across multiple screens while taking advantage of the HX arm’s adjustment capabilities.

Select part number 98-009-026 for use with HX arms having a polished aluminum finish; select part nu

  • Increases viewing comfort: Helps reduce eye, back and neck strain
  • The hinged bow allows monitors to pan outward independently, ideal for sharing screens
  • Optimize the viewing range for enhanced ergonomic comfort by rotating monitors inward using the hinged bow
  • Independent, quick release monitor pivots with effortless rotation, pan and tilt for custom positioning of each monitor
  • Includes integrated cable management guides for hassle-free routing of cables

Product Benefits

  • Increases viewing comfort: Helps reduce eye, back and neck strain
  • The hinged bow allows monitors to pan outward independently, ideal for sharing screens
  • Optimize the viewing range for enhanced ergonomic comfort by rotating monitors inward using the hinged bow
  • Independent, quick release monitor pivots with effortless rotation, pan and tilt for custom positioning of each monitor
  • Includes integrated cable management guides for hassle-free routing of cables



Specifications

  • Part Number: 98-009-216 (white), 98-009-026 (polished aluminum)
  • Description: HX Triple Monitor Bow Kit
  • Included: Three (3) monitor pivots, triple hinged bow and handle; requires HX Single or Dual Monitor Arm (order separately)
  • Select 98–009–026 for HX arms with polished aluminum finish:
  • Single arms: 45–475–026, 45–478–026
  • Dual arms: 45–476–026, 45–479–026
  • Select 98–009–216 for HX arms with a white or silver finish:
  • Single arms: 45–475–216, 45–475–231, 45–478–216, 45–478–231
  • Dual arms: 45–476–216, 45–476–231, 45–479–026, 45–479–231
  • Streamline cable management that routes cables under arm, within extension, and neatly across bow.
  • Mounting Standards: VESA FDMI MIS–D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
  • * Weight Capacity: Individual LCD weight = 2.0–10.2 lbs (1.0–4.6 kg) per monitor. Total LCD weight = 6.0–30.6 lbs (3.0–13.8 kg)
  • Hinge bow pivots 40° inward and 90° outward
  • Up to 24.5" (60 cm) extended reach and 11.5" (29.2 cm) vertical height adjustment
  • † Tilt Range: 70° backward, –5° forward
  • Pivots feature quick install and release and feature effortless portrait to landscape 6° pan and tilt
  • ‡ Works with three displays with diagonal screen–size up to 24"
  • Portrait/landscape rotation with lockout
  • Shipping Dimensions: 28.3" x 18.5" x 7.5" (72 x 47 x 19 cm)
  • Shipping Weight: 19.1 lbs (8.7 kg)
  • Warranty: Ten (10) years
